CPU
Dual Intel® Xeon® Scalable Processors, Socket LGA-3647 (Socket P0)，each processor supports Intel® Ultra Path Interconnect (UPI) of up to 10.4 GT/s
-
芯片组
Intel® C620 Series (Support C622/C624/C628 PCH)
-
显示
1 * VGA(DB15/F): max resolution up to 1920*1200@60Hz
-
内存
Support DDR4-2666/2400/2133MHz，16 * ECC U-DIMM Slot, Up to 2TB
-
存储
1 * M.2 (NGFF) Key-M Slot (PCIe x4 NVMe SSD, 2242/2260/2280) ；2 * SATA 3.0 (SATA 7P) ；12 * SATA 3.0 (SAS1~3)
-
网络
1 * Intel® X550 10GBase-T Ethernet Controller with 2 LAN，2 * RJ45
-
音频
Realtek ALC662 5.1 Channel HDA Codec, 1 * Front Audio Header (Line-Out + MIC)
-
扩展
4 * PCI-E 16x Slot (Gen3) 1，1 * PCI-E 8x Slot (Gen3)
-
BMC
ASpeed AST2500 Baseboard Management Controller (BMC)，Supports IPMI 2.0 support ，1 * BMCICE Header
-
COM
1 * RS232 (COM1, DB9/M)
-
USB
2 * USB3.0 (TYPE-A, Rear IO) ；2 * USB3.0 (Header, Internal) ；2 * USB2.0 (Header, Internal)
-
其他
1 * XDP Connector ；1 * Front Panel Header (HDD LED+PWR LED+PWR-ON+RESET) ；4 * 4P FAN ；2 * 5P FAN ；1 * COM DBG Header 1 * JTG PLD Header 1 * IPMB Header ；1 * FPB ID Header ；1 * VR Control Header 1 * FPB NMI Header ；1 * Buzzer Header 1 * PMBus Header ；1* Debug Mode Enable/Disable Select Jumper 1 * BMC Enable/Disable Select Jumper ；1 * JTG Enable/Disable Select Jumper 1 * Power Clear Jumper ；1 * AT or ATX Select Jumper 2 * CMOS Clear Jumper
-
TPM
SLB9670VQ2.0, TPM2.0 onboard
-
系统
Linux, Windows Server 2016, Windows10
-
环境温度
Storage: -20~75℃ Operating: 0~60℃
-
BIOS
AMI UEFI BIOS (Support Watchdog Timer)
-
供电接口
2 * ATX 8P CPU Power Input Connector ；1 * ATX 24P Power Input Connector
-
尺寸
330mm * 305mm
